SMC PSE541-01 COMPACT PRESSURE SWITCH
Pneumatic Pressure Sensor
References
smc:PSE541-01
rubix:2606810
Technical specifications
| Type | Positive pressure 0 to 1 Mpa |
|---|---|
| Execution | Orifice size: R 1/8 |
| Min. tension | 12 V |
Product details : SMC PSE541-01 COMPACT PRESSURE SWITCH
Digital pressure switch
Pressure rates: up to 10 MPa
Accuracy: up to 1% F.S.
Output: IO-Link, NPN/PNP or analogue (Voltage/Current)
Enclosure up to IP65.
Pressure rates: up to 10 MPa
Accuracy: up to 1% F.S.
Output: IO-Link, NPN/PNP or analogue (Voltage/Current)
Enclosure up to IP65.
•Compact pressure sensor for pneumatics
•Proof pressure: 500kPa
•Accuracy (ambient temp. of 25°C): ¹2%F.S. or less
•Repeatability: ¹0.2%F.S. or less
•Enclosure: IP40
Sensor Range: 1 [For Vacuum (0~-101kPa)]
Accuracy: ±2%F.S.
Port Size: 01 [R 1/8(w/M5 Female)]
Option: None
•Proof pressure: 500kPa
•Accuracy (ambient temp. of 25°C): ¹2%F.S. or less
•Repeatability: ¹0.2%F.S. or less
•Enclosure: IP40
Sensor Range: 1 [For Vacuum (0~-101kPa)]
Accuracy: ±2%F.S.
Port Size: 01 [R 1/8(w/M5 Female)]
Option: None
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 28x24x12 mm |
|---|---|
| Logistic Weight | 57 g |
| Type | Positive pressure 0 to 1 Mpa |
| Execution | Orifice size: R 1/8 |
| Min. tension | 12 V |
| Max. tension | 24 V |
Show UNSPSC/ECL@SS
£ 66.25 excl. VAT
/ Each
£ 79.50 incl. VAT
Delivery usually within ( 4 ) days
