FESTO 535486 LINEAR/SWIVEL CLAMP CLR-25-20-L-P-A-K11-R8
Cylinder Swing Clamp
References
festo:CLR-25-20-L-P-A-K11-R8
rubix:134A1123
manufacturer :535486
ean:4052568169022
Technical specifications
| Type | Cylinder Swing Clamp |
|---|---|
| Cylinder diameter | 25 mm |
Product details : FESTO 535486 LINEAR/SWIVEL CLAMP CLR-25-20-L-P-A-K11-R8
Linear/swivel clamp CLR-25-20-L-P-A-K11-R8 clamping system with linear and swivel motion 90 degrees to the left. standard hole pattern according to ISO 21287. With dust and weld spatter protection. Total stroke=33 mm, Piston diameter=25 mm, Piston rod thread=M6, Swivel angle=90 deg +/- 3 deg, Clamping stroke=20 mm
Technical specifications
Attributes
| Logistic Weight | 571,9 g |
|---|---|
| Type | Cylinder Swing Clamp |
| Cylinder diameter | 25 mm |
| Min. temperature | -10 °C |
| Max. temperature | 80 °C |
| Cylinder stroke | 20 mm |
| Max. service pressure | 10 bar |
| Fixation centre-to-centre distance | 26 mm |
| Design size | 25 |
Show UNSPSC/ECL@SS
£ 445.14 excl. VAT
/ Each
£ 534.17 incl. VAT
Delivery usually within ( 6 ) days
