MECALINE F50F Tyre Coupling Hub F Type
Hub for Tyre Coupling
References
mecaline:866370
rubix:45036035
ean:3660338205101
Product details : MECALINE F50F Tyre Coupling Hub F Type
Tyre coupling flange F Type, Half body can be combined with another F type or H type and matching tyre to produce the desired tyre coupling. Use Mecaline Coupling catalogue for selection process. F type means bush is installed from the inside of the hub, and H type means bush is installed from the outside of the hub. Tyre couplings can accommodate simultaneous misalignment in all planes without imposing undue loads on ajacent bearings.
F050 F tyre coupling hub
Strengths
GG25 Cast Iron
Applications
For transferring power through 2 shafts and to compensate mis-alignment
Technical specifications
Attributes
| Size | 50 |
|---|---|
| Material | steel |
| Min. temperature | -15 °C |
| Max. temperature | 70 °C |
| Outer diameter | 100 mm |
| Nominal torque | 53 N.m |
| Max speed | 4500 rpm |
| Angular offset | 4 ° |
| Radial offset | 3 mm |
| Weight | 1.067 kg |
| Type | f |
Show UNSPSC/ECL@SS
£ 44.97 excl. VAT
/ Each
£ 53.96 incl. VAT
In stock: Next day delivery
