SMC KK6S-03F FEMALE CONN RC3/8
KK Socket Coupler
References
smc:KK6S-03F
rubix:132A8811
Technical specifications
| Connection 1 | R 3/8 |
|---|---|
| Material | PBT (Spacer, Chuck);C2680 (Sleeve);C3604 (Collar, Socket Body);304 Stainless Steel (Sleeve Spring, Valve Spring);NBR (Plug O-Ring);PBT (Valve Seat, Valve);NBR (Valve Seat O-Ring);FKM (Valve O-Ring);304 Stainless Steel, NBR (Gasket) |
Product details : SMC KK6S-03F FEMALE CONN RC3/8
S coupler for general purpose with Plug and Socket
Applicable tubing from Ø 3.2 to Ø 16
Thread, sizes: M, R, Rc, from M5 to 3/4
Fluid temperature: -5 to 60 °C, water: 5 to 40 °C
One-touch fitting type standardized
With sleeve lock mechanism (Except KK2).
Applicable tubing from Ø 3.2 to Ø 16
Thread, sizes: M, R, Rc, from M5 to 3/4
Fluid temperature: -5 to 60 °C, water: 5 to 40 °C
One-touch fitting type standardized
With sleeve lock mechanism (Except KK2).
•Female Thread.
•Body size: M5, 1/8, 1/4, 1/2.
•Applicable Port Size: M5, Rc1/8, Rc1/4, Rc3/8, Rc1/2.
Body Size: 6 (1/2)
Piping Port Size: Rc 3/8
•Body size: M5, 1/8, 1/4, 1/2.
•Applicable Port Size: M5, Rc1/8, Rc1/4, Rc3/8, Rc1/2.
Body Size: 6 (1/2)
Piping Port Size: Rc 3/8
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 32x59x32 mm |
|---|---|
| Logistic Weight | 91 g |
| Connection 1 | R 3/8 |
| Material | PBT (Spacer, Chuck);C2680 (Sleeve);C3604 (Collar, Socket Body);304 Stainless Steel (Sleeve Spring, Valve Spring);NBR (Plug O-Ring);PBT (Valve Seat, Valve);NBR (Valve Seat O-Ring);FKM (Valve O-Ring);304 Stainless Steel, NBR (Gasket) |
| Profile | KK6S |
| Max. temperature | 60 °C |
| Min. temperature | -5 °C |
Show UNSPSC/ECL@SS
£ 20.30 excl. VAT
/ Each
£ 24.36 incl. VAT
Delivery usually within ( 4 ) days
