SMC AFM20-F02C-D MIST SEPARATOR
Mist Separator
References
smc:AFM20-F02C-D
rubix:261A4053
manufacturer :02102112
Technical specifications
| Threading diameter (inch) | 1/4 '' |
|---|---|
| Filter fineness | 0.3 µm |
Product details : SMC AFM20-F02C-D MIST SEPARATOR
Modular-style Mist Separator
ISO 8573-1:2010 compliant
Nominal filtration rating 0.3 µm
Maximum flow rate up to 1100 l/min (ANR, 0.7MPa).
ISO 8573-1:2010 compliant
Nominal filtration rating 0.3 µm
Maximum flow rate up to 1100 l/min (ANR, 0.7MPa).
•ISO 8573-1:2010 compliant
•Nominal filtration rating 0.3 µm
•Maximum flow rate up to 1100 l/min (ANR, 0.7MPa).
Body Size: 20
Thread: F (G)
Port Size: 02 (1/4)
Mounting: w/o Mounting Option
Float type auto drain: C [Float Type Auto Drain (N.C.)]
Bowl type: Polycarbonate Bowl
Filter Regulator Drain Port: Standard
Flow Direction: Left to Right
Drain Cock w/Barb Fitting: None
Pressure Unit: Name Plate and Pressure Gauge
•Nominal filtration rating 0.3 µm
•Maximum flow rate up to 1100 l/min (ANR, 0.7MPa).
Body Size: 20
Thread: F (G)
Port Size: 02 (1/4)
Mounting: w/o Mounting Option
Float type auto drain: C [Float Type Auto Drain (N.C.)]
Bowl type: Polycarbonate Bowl
Filter Regulator Drain Port: Standard
Flow Direction: Left to Right
Drain Cock w/Barb Fitting: None
Pressure Unit: Name Plate and Pressure Gauge
Strengths
•Mist separator
Can be used in a more compact modular design
Bowl can be attached and detached with one hand
Turn proof structure at pressurized state for bowl removal
Standard drain cock for one-touch drain exhaust
Cost effective and clean looking design
Can be used in a more compact modular design
Bowl can be attached and detached with one hand
Turn proof structure at pressurized state for bowl removal
Standard drain cock for one-touch drain exhaust
Cost effective and clean looking design
Technical specifications
Attributes
| Threading diameter (inch) | 1/4 '' |
|---|---|
| Filter fineness | 0.3 µm |
| Material | Die-Cast Zinc (Body) |
| Volume flow rate | 200 l/min |
| Min. temperature | -5 °C |
| Max. temperature | 60 °C |
Show UNSPSC/ECL@SS
£ 38.26 excl. VAT
/ Each
£ 45.91 incl. VAT
Delivery usually within ( 4 ) days
