TSUBAKI 70150050000-M3.05 RS50 NEPTUNE 1 CHAIN FOR CORROSIVE ENV 10FT


ANSI Neptune Chain

References
tsubaki:RS50 N.E.P.1 RP
rubix:267A0666
manufacturer :0150050000
ean:8718472782400
brand logo
brand logo
Technical specifications
Chain pitch15.875 mm
Chain length3050 mm
ProfileSimplex (1)
See all Specifications

Product details : TSUBAKI 70150050000-M3.05 RS50 NEPTUNE 1 CHAIN FOR CORROSIVE ENV 10FT


ANSI Neptune™ Chain is a Tsubaki ANSI chain that has undergone a special surface treatment. The link plates, bushes and pins have a special three stage layer applied in order to provide the maximum protection from the operating or environmental conditions. (Spring clips are SUS301). Neptune™ Rollers have a special coating designed to resist the corrosive conditions as well as the severe dynamic contact between roller and sprocket. This chain is suitable for use in environments exposed to seawater, acid-rain and other adverse weather conditions. This chain does not contain any chemically hazardous substances such as Hexavalent Chromium, Lead, Cadmium and Mercury as regulated by RoHS.

Technical specifications


Attributes
Chain pitch15.875 mm
Chain length3050 mm
ProfileSimplex (1)
ChainASA 50-1
ISO code10A-1
Weight3305 kg
Inner width min.9.53 mm
Roller diameter10.16 mm
Pin length22.6 mm
Tensile strength min.28.4 kN
Plate height15 mm
Plate thickness2 mm
Inner link width9.53 mm
Chain pin diameter5.09 mm
Show UNSPSC/ECL@SS
£ 205.14 excl. VAT
/ Each
£ 246.17 incl. VAT
  • Usually arrives within 14 working days
