DORMER C13516.0 DRILL 16.00 MM 5984613
Key-way cutter HSCO C135
References
dormer:C13516.0
rubix:1068449
ean:7320760057551
Technical specifications
| Diameter | 16 mm |
|---|---|
| Type of tail | WELDON |
| Tail diameter | 16 mm |
Product details : DORMER C13516.0 DRILL 16.00 MM 5984613
HSS-E-PM Mid-length key-way cutter with weld-on shaft DIN 844L N 30° uncoated 2-cutter for non-alloyed steel <700 N/mm². Nickel and copper alloys.
FRAISE 16.00 2D NORMAL QC C135 HSCO 8
Applications
• Machining steel soft steel (<120 HB <400 N/mm²)
• Construction steel carburised steel (<200 HB <700 N/mm²)
• nickel non-alloyed (<200 HB <700 N/mm²)
• Copper (<100 HB <350 N/mm²)
• Béta-Brass Bronze (<200 HB <700 N/mm²)
• Alfa-Brass (<200 HB <700 N/mm²)
• Construction steel carburised steel (<200 HB <700 N/mm²)
• nickel non-alloyed (<200 HB <700 N/mm²)
• Copper (<100 HB <350 N/mm²)
• Béta-Brass Bronze (<200 HB <700 N/mm²)
• Alfa-Brass (<200 HB <700 N/mm²)
Technical specifications
Attributes
| Diameter | 16 mm |
|---|---|
| Type of tail | WELDON |
| Tail diameter | 16 mm |
| Number of teeth | 2 |
| Total length | 123 mm |
| Body material | HSS-E |
| Machining material | Non-alloyed steel, nickel and copper alloys |
| Capacity length | 74.5 mm |
| Cutting angle | 30 ° |
Show UNSPSC/ECL@SS
£ 81.81 excl. VAT
/ Each
£ 98.17 incl. VAT
Usually arrives within 14 working days
