BLICKLE GTH 202/35K HEAVY DUTY WHEEL
Pressed steel swivel castor, heavy duty design, with top plate fitting, with brake system 'stop-fix' Heavy duty wheel, with 'Blickle EasyRoll' elastic solid rubber tyres, with aluminium wheel centre, electrically conductive
References
blickle:GTH 202/35K
rubix:221A2358
manufacturer :442129
ean:4047526442125
Technical specifications
| Load capacity | 1600 kg |
|---|---|
| Wheel diameter | 200 mm |
| Wheel width | 80 mm |
Product details : BLICKLE GTH 202/35K HEAVY DUTY WHEEL
Bracket: LH series
- strong pressed steel, zinc-plated, blue-passivated, Cr6-free
- heavy fork and top plate
- double ball bearing in the swivel head
- bolted and secured central kingpin, extremely strong
- particularly resistant to shocks and impact due to four specially-shaped, hardened bearing seats
Wheel: ALEV series
- tyre: high-quality elastic solid rubber "Blickle EasyRoll" in smooth rolling quality, hardness 71 Shore A, colour black
- wheel centre: die-cast aluminium
- high chemical resistance to many aggressive substances, except oils
- operating temperature: -20 °C to +80 °C, temporarily up to +100 °C, reduced load capacity over +60 °C
- electrical conductivity (ohmic resistance) ≤ 104 Ω
Technical specifications
Attributes
| Logistic Weight | 7247 g |
|---|---|
| Load capacity | 1600 kg |
| Wheel diameter | 200 mm |
| Wheel width | 80 mm |
| Wheel housing/rim material | Cast Iron |
| Running sole/tire material | Polyurethane |
| Running sole / tire colour | Brown |
| Shore A Hardness | 92 Shore |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| 80 mm |
Show UNSPSC/ECL@SS
£ 160.65 excl. VAT
/ Each
£ 192.78 incl. VAT
Usually arrives within 14 working days
