SKF SPHERICAL ROLLER BEARING 23164CC/W33

Spherical roller bearing

See technical information
References
SKF:23164 CC/W33
Rubix:104A9823
Manufacturer :36075
EAN:7316570017526
brand logo
Technical specifications
Inner diameter320 mm
Outer diameter540 mm
Width176 mm
See all Specifications

Product details : SKF SPHERICAL ROLLER BEARING 23164CC/W33


Spherical roller bearings feature two symmetrical rows of rollers rolling between a spherical raceway common to both rows on the outer ring and two separate raceways on the inner ring. The center of the spherical raceway on the outer ring lies on the axis at the center of the bearing.

Technical specifications


Attributes
Logistics dimensions (L x W x H)176x540x540 mm
Logistic Weight165300 g
Inner diameter320 mm
Outer diameter540 mm
Width176 mm
Bearing Clearancecn
Cagesteel
Sealingopen
Weight165 kg
Reference speed850 rpm
Limit speed1100 rpm
Basic static load, radial - C0r6000000 N
Basic dynamic load, radial - Cr3280000 N
Show UNSPSC/ECL@SS
£ 8,824.60 excl. VAT
/ Each
£ 10,589.52 incl. VAT
  • In stock: Next day delivery
