SKF SY 1.1/4 TF/VA228 HIGH TEMPERATURE BEARINGS

Ball bearing unit

References

SKF:SY 1.1/4 TF/VA228

Rubix:237A4325

Manufacturer :114750

EAN:07316571381107

Inner diameter	31.75 mm
Fixation centre-to-centre distance	133 mm
Material	cast iron (housing);steel (bearing)

Y pedestal bearing unit for high temperatures with cast housing and set-screw fastening.

- Accommodate heavy loads in different directions
- High degree of stiffness
- Narrow design

Attributes

Logistics dimensions (L x W x H)	47,9x160x31,75 mm
Logistic Weight	1553 g
Inner diameter	31.75 mm
Fixation centre-to-centre distance	133 mm
Material	cast iron (housing);steel (bearing)
Total bearing width	42.9 mm
Outer diameter	46.1 mm
Diameter of fixation holes	12 mm
Height	93 mm
Length	160 mm
Series	sy
Weight	1.5 kg
Number of holes	2
Width	45 mm

Show UNSPSC/ECL@SS

£ 195.53 ^{excl. VAT}

/ Each

£ 234.64 ^{incl. VAT}
