Deep groove ball bearing Timken 62300-2RS, Outer diameter: 35 mm | Width: 17 mm | Inner diameter: 10 mm
Ball bearing
See technical informationReferences
Timken:62300-2RS
Rubix:100A3778
EAN:0053893724584
Product details : TIMKEN 62300-2RS BALL BEARING WITH SEALS
A non-seperable single row ball bearing with deep raceway grooves and rubber seals on both sides. Suitable for running at high speeds and can accommodate axial loads in both directions, in addition to radial loads, due to the close conformity between the raceway grooves and balls.
Technical specifications
Attributes
| Inner diameter | 10 mm |
|---|---|
| Outer diameter | 35 mm |
| Width | 17 mm |
| Sealing | two rubber seals |
| Bearing Clearance | cn |
| Series | 623 series (extra-medium wide type) |
| Material | steel |
| Cage | steel |
| Limit speed | 15000 rpm |
| Precision | p0 (normal / abec 1) |
| Basic static load, radial - C0r | 3.4 N |
| Basic dynamic load, radial - Cr | 8.1 N |
| Weight | 0.07 kg |
Show UNSPSC/ECL@SS
£ 12.88 excl. VAT
/ Each
£ 15.46 incl. VAT
- Delivery usually within ( 7 ) days
