BLICKLE 50MM SWIVEL CASTOR LKPA-VSTH 50K
Light duty swivel castor, with bolt hole fitting Wheel, with solid rubber tyres, with synthetic rim, with steel thread guard
References
blickle:LKPA-VSTH 50K
rubix:156A4687
manufacturer :754816
ean:4047526106171
Technical specifications
| Load capacity | 150 kg |
|---|---|
| Wheel diameter | 50 mm |
| Wheel width | 33 mm |
Product details : BLICKLE 50MM SWIVEL CASTOR LKPA-VSTH 50K
Bracket: LKRA series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
- double ball bearing in the swivel head
- strong central kingpin
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: VPA series
- tyre: high-quality solid rubber, hardness 80 Shore A, colour grey, non-marking, non-staining
- rim: high-quality nylon 6 or polypropylene in the electrically conductive version "-EL", impact resistant, colour black
- high chemical resistance to many aggressive substances, except oils
- operating temperature: -20 °C to +60 °C, reduced load capacity over +30 °C
Technical specifications
Attributes
| Logistic Weight | 659 g |
|---|---|
| Load capacity | 150 kg |
| Wheel diameter | 50 mm |
| Wheel width | 33 mm |
| Wheel housing/rim material | Steel |
| Running sole/tire material | Polyurethane |
| Type of bearing | Ball bearing |
| Running sole / tire colour | Brown |
| Shore A Hardness | 92 Shore |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| 73 mm | |
| 33 mm |
Show UNSPSC/ECL@SS
£ 27.17 excl. VAT
/ Each
£ 32.60 incl. VAT
Usually arrives within 14 working days
