WALTERPROT E2031436-M8 HAND- AND MACHINE TAPS HSS/-E 5603126

Machine Tap

See technical informationSee documents

References

Walter Prototyp:E2031436-M8
Rubix:357A4962
Manufacturer :5603126
EAN:4042446188573
brand logo

Technical specifications

Threadingm8
Threading diameter8 mm
Typemetric blind bores and through-bores
See all Specifications

Documents

Product details : WALTERPROT E2031436-M8 HAND- AND MACHINE TAPS HSS/-E 5603126

ALTIUS

Strengths

•For short-chipping materials
Nitrided

Applications

Blind Hole Thread;Through Hole Thread

Technical specifications

Attributes
Threadingm8
Threading diameter8 mm
Typemetric blind bores and through-bores
With cooling sprayno
Direction of threadingright
Drilling diameter6.982 mm
Tail diameter8 mm
Square drive adapter6.2 mm
Thread depth35 mm
Angle of helix0 °
Coatingticn
Total length180 mm
Body materialhss-e / pm
Threadingm8x1,25
No. of threads per inch20.32
Tolerance6hx
£ 105.96 excl. VAT
/ Each
£ 127.15 incl. VAT
  • Usually arrives within 14 working days
