DORMER E252M12 TAP M12 X 1.75 MM 5975921
Machine thread-cutters E252
References
dormer:E252M12
rubix:1006298
ean:7320760087275
Technical specifications
| Threading | M12 |
|---|---|
| Threading diameter | 12 mm |
| Total length | 110 mm |
Product details : DORMER E252M12 TAP M12 X 1.75 MM 5975921
HSS-E-PM Machine thread-cutter for metric threaded SHARK white ring nitrided DIN 376 shape C straight grooves 2xD blind and continuous holes for cast iron and synthetic materials such as duraplastics.
Applications
• Cast Iron lamellar (<150 HB>500 N/mm²)
• Cast Iron lamellar (>150<300 HB>500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Plastic - Duraplastics
• Cast Iron lamellar (>150<300 HB>500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Plastic - Duraplastics
Technical specifications
Attributes
| Threading | M12 |
|---|---|
| Threading diameter | 12 mm |
| Total length | 110 mm |
| Body material | HSS-E |
| Type | Metric blind bores and through-bores |
| With cooling spray | No |
| Drilling diameter | 10.3 mm |
| Square drive adapter | 9 mm |
| Coating | Nitride |
Show UNSPSC/ECL@SS
£ 36.14 excl. VAT
/ Each
£ 43.37 incl. VAT
Usually arrives within 14 working days
