DORMER E471M3 SPIRAL POINT TAP M3 X 0.50 MM 6554521
Machine thread-cutters E471
References
dormer:E471M3
rubix:2557157
ean:7320760674628
Technical specifications
| Threading diameter | 3 mm |
|---|---|
| Input | 3.5 |
| Total length | 56 mm |
Product details : DORMER E471M3 SPIRAL POINT TAP M3 X 0.50 MM 6554521
HSS-E Machine thread-cutter for metric thread SHARK green ring uncoated DIN 376 shape B cut 2.5xD continuous holes for brass and bronze <200 HB. Aluminium and aluminium-magnesium alloys Si <10% and synthetic materials such as thermoplastics.
Applications
• Béta-Brass Bronze (<200 HB <700 N/mm²)
• Copper - Alfa-Brass (<200 HB <700 N/mm²)
• Aluminium/Magnesium - Aluminium Magnesium alloyed (<100 HB <350 N/mm²)
• Aluminium/Magnesium - Aluminium alloyed Silicon 0.5% (<150 HB <500 N/mm²)
• Aluminium/Magnesium - Aluminium alloyed Silicon 0.5% < 10% (<120 HB <400 N/mm²)
• Plastic - Thermoplastics
• Copper - Alfa-Brass (<200 HB <700 N/mm²)
• Aluminium/Magnesium - Aluminium Magnesium alloyed (<100 HB <350 N/mm²)
• Aluminium/Magnesium - Aluminium alloyed Silicon 0.5% (<150 HB <500 N/mm²)
• Aluminium/Magnesium - Aluminium alloyed Silicon 0.5% < 10% (<120 HB <400 N/mm²)
• Plastic - Thermoplastics
Technical specifications
Attributes
| Threading diameter | 3 mm |
|---|---|
| Input | 3.5 |
| Total length | 56 mm |
| Body material | HSS-E / PM |
| Type | Metric through-bores |
| With cooling spray | No |
| Square drive adapter | 3.5 mm |
| Coating | Blank |
Show UNSPSC/ECL@SS
£ 19.89 excl. VAT
/ Each
£ 23.87 incl. VAT
Usually arrives within 14 working days
