DORMER E5501 TAP 1 INCH X 11 5976452
Machine thread-cutters E550
References
dormer:E5501
rubix:021324
ean:7320760099445
Technical specifications
| Input | 25 |
|---|---|
| Total length | 109 mm |
| Body material | HSS |
Product details : DORMER E5501 TAP 1 INCH X 11 5976452
HSS Machine thread-cutters for Rc thread uncoated ISO 2284 shape C straight grooves 1.5xD blind and continual holes for cast iron and copper.
TARAUD MACHINE 1 RC E550 BSPT ISO 2284
Applications
• Cast Iron lamellar (<150 HB >500 N/mm ²)
• Cast iron lamellar (>150<300 HB >500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Ductile cast iron/malleable cast iron (>200<300 HB >700<1000 N/mm²)
• Copper (<100 HB <350 N/mm²)
• Cast iron lamellar (>150<300 HB >500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Ductile cast iron/malleable cast iron (>200<300 HB >700<1000 N/mm²)
• Copper (<100 HB <350 N/mm²)
Technical specifications
Attributes
| Input | 25 |
|---|---|
| Total length | 109 mm |
| Body material | HSS |
| Type | British blind bores and through-bores |
| With cooling spray | No |
| Drilling diameter | 30 mm |
| Square drive adapter | 25 mm |
| Coating | Blank |
Show UNSPSC/ECL@SS
£ 204.10 excl. VAT
/ Each
£ 244.92 incl. VAT
Usually arrives within 14 working days
