BLICKLE GTHN 202/35H7 GTHN-202-35H7 WHEEL
Pressed steel swivel castor, heavy duty design, with top plate fitting Heavy duty wheel, with 'Blickle EasyRoll' elastic solid rubber tyres, with aluminium wheel centre, electrically conductive
References
blickle:GTHN 202/35H7
rubix:223A5510
manufacturer :459867
ean:4047526459864
Technical specifications
| Load capacity | 1400 kg |
|---|---|
| Wheel diameter | 200 mm |
| Wheel width | 80 mm |
Product details : BLICKLE GTHN 202/35H7 GTHN-202-35H7 WHEEL
Bracket: LH series
- strong pressed steel, zinc-plated, blue-passivated, Cr6-free
- heavy fork and top plate
- double ball bearing in the swivel head
- bolted and secured central kingpin, extremely strong
- particularly resistant to shocks and impact due to four specially-shaped, hardened bearing seats
Wheel: ALEV series
- tyre: high-quality elastic solid rubber "Blickle EasyRoll" in smooth rolling quality, hardness 71 Shore A, colour black
- wheel centre: die-cast aluminium
- high chemical resistance to many aggressive substances, except oils
- operating temperature: -20 °C to +80 °C, temporarily up to +100 °C, reduced load capacity over +60 °C
- electrical conductivity (ohmic resistance) ≤ 104 Ω
Technical specifications
Attributes
| Logistic Weight | 6950 g |
|---|---|
| Load capacity | 1400 kg |
| Wheel diameter | 200 mm |
| Wheel width | 80 mm |
| Wheel housing/rim material | Cast Iron |
| Running sole/tire material | Polyurethane |
| Running sole / tire colour | Brown |
| Shore A Hardness | 92 Shore |
| Min. temperature | -30 °C |
| Max. temperature | 70 °C |
| 80 mm |
Show UNSPSC/ECL@SS
£ 161.85 excl. VAT
/ Each
£ 194.22 incl. VAT
Usually arrives within 14 working days
