BLICKLE 250MM HVY DUTY WHEEL GTHN 252/50H7
Pressed steel swivel castor, heavy duty design, with top plate fitting Heavy duty wheel, with 'Blickle EasyRoll' elastic solid rubber tyres, with aluminium wheel centre, non-marking, grey
References
blickle:GTHN 252/50H7
rubix:157A5254
manufacturer :462382
ean:4047526462383
Technical specifications
| Load capacity | 1800 kg |
|---|---|
| Wheel diameter | 250 mm |
| Wheel width | 80 mm |
Product details : BLICKLE 250MM HVY DUTY WHEEL GTHN 252/50H7
Bracket: LH series
- strong pressed steel, zinc-plated, blue-passivated, Cr6-free
- heavy fork and top plate
- double ball bearing in the swivel head
- bolted and secured central kingpin, extremely strong
- particularly resistant to shocks and impact due to four specially-shaped, hardened bearing seats
Wheel: ALEV series
- tyre: high-quality elastic solid rubber "Blickle EasyRoll" in smooth rolling quality, hardness 65 Shore A, colour grey, non-marking
- wheel centre: die-cast aluminium
- high chemical resistance to many aggressive substances, except oils
- operating temperature: -20 °C to +80 °C, temporarily up to +100 °C, reduced load capacity over +60 °C
Technical specifications
Attributes
| Logistic Weight | 9770 g |
|---|---|
| Load capacity | 1800 kg |
| Wheel diameter | 250 mm |
| Wheel width | 80 mm |
| Wheel housing/rim material | Cast Iron |
| Running sole/tire material | Polyurethane |
| Running sole / tire colour | Brown |
| Shore A Hardness | 92 Shore |
| Min. temperature | -30 °C |
| Max. temperature | 70 °C |
| 80 mm |
Show UNSPSC/ECL@SS
£ 212.94 excl. VAT
/ Each
£ 255.53 incl. VAT
Usually arrives within 14 working days
