TSUBAKI 0132080202 RS80-NP-2 CONNECTING LINK (COTTERPIN)
RS80-NP-2 Tsubaki ANSI connecting link (cotterpin)
References
tsubaki:RS80 NP 2 CL CP
rubix:267A0069
manufacturer :0132080202
ean:8718472007459
Technical specifications
| Chain | ANSI NP Chain |
|---|---|
| Chain pitch | 25.4 mm |
Product details : TSUBAKI 0132080202 RS80-NP-2 CONNECTING LINK (COTTERPIN)
ANSI NP Chain is a Tsubaki ANSI G7 chain that has been plated with Nickel. NP chain has a light corrosion resistance and an attractive appearance. NP chain is suitable for outdoor conditions exposed to water. There is a 15% reduction in Maximum Allowable Load compared to the corresponding ANSI G7 chain, so please take this into account when making your chain selection. The working temperature range is: -10°C to +60°C.
Technical specifications
Attributes
| Logistic Weight | 119 g |
|---|---|
| Chain | ANSI NP Chain |
| Chain pitch | 25.4 mm |
| Weight | 119 g |
| Inner width min. | 15.88 mm |
| Roller diameter | 15.88 mm |
| Plate height | 24.1 mm |
| Plate thickness | 3.2 mm |
| Pin length | 67.5 mm |
| Material | Nickel-Plated |
| Type | Roller Chain |
| Plate type | Link |
| Chain pin diameter | 7.94 mm |
Show UNSPSC/ECL@SS
£ 21.52 excl. VAT
/ Each
£ 25.82 incl. VAT
Usually arrives within 14 working days
