Deep groove ball bearing SKF 6208-2Z/C4VT127, Outer diameter: 80 mm | Width: 18 mm | Inner diameter: 40 mm
SKF Deep groove ball bearing 6208 Series
References
skf:6208-2Z/C4VT127
rubix:237A4119
manufacturer :179444
ean:07316572036150
Technical specifications
| Inner diameter | 40 mm |
|---|---|
| Outer diameter | 80 mm |
| Width | 18 mm |
Product details : SKF 6208-2Z/C4VT127 VARIANTS FROM DA INCLUDING INCH SIZES
Deep groove ball bearings are particularly versatile. They are suitable for high and very high speeds, accommodate radial and axial loads in both directions and require little maintenance. Because deep groove ball bearings are the most widely used bearing type, they are available from SKF in many designs, variants and sizes.
Strengths
- Ease of mounting via adapter sleeves or withdrawal sleeves
- Integral sealing prolongs bearing service life
- Typical benefits of single row deep groove ball bearings
- Integral sealing prolongs bearing service life
- Typical benefits of single row deep groove ball bearings
Technical specifications
Attributes
| Logistic Weight | 368 g |
|---|---|
| Inner diameter | 40 mm |
| Outer diameter | 80 mm |
| Width | 18 mm |
| Sealing | Two metal shields |
| Bearing Clearance | C4 |
| Series | 62 |
| Material | Bearing steel |
| Reference speed | 18000 rpm |
| Limit speed | 9000 rpm |
| Basic static load, radial - C0r | 19000 N |
| Basic dynamic load, radial - Cr | 32500 N |
Show UNSPSC/ECL@SS
£ 151.18 excl. VAT
/ Each
£ 181.42 incl. VAT
Usually arrives within 14 working days
