SNR BEARING UNIT SUCFL204
SNR - Bearing Unit - SUCFL.204
References
snr:SUCFL.204
rubix:205A8649
ean:3413529501816
Technical specifications
| Inner diameter | 20 mm |
|---|---|
| Width | 31 mm |
| Fixation centre-to-centre distance | 90 mm |
Product details : SNR BEARING UNIT SUCFL204
stainless steel cast housing,stainless steel insert ball bearing with socket set screws,seal with slinger, food grease
Technical specifications
Attributes
| Inner diameter | 20 mm |
|---|---|
| Width | 31 mm |
| Fixation centre-to-centre distance | 90 mm |
| Height | 112 mm |
| Length | 58.5 mm |
| Series | SUCFL200 |
| Total bearing width | 33.3 mm |
| Diameter of fixation holes | 12 mm |
| Number of holes | 2 |
| Basic static load, radial - C0r | 6800 N |
| Basic dynamic load, radial - Cr | 10100 N |
| Outer diameter | 47 mm |
| Weight | 0.46 kg |
Show UNSPSC/ECL@SS
Usually arrives within 14 working days
