SNR 10R71924CVUJ74 PRECISION BALL BEARINGS

Precision / Spindle bearing SNR 10R71924CVUJ74, Inner diameter: 120 mm | Outer diameter: 165 mm | Width: 22 mm

SNR - Precision ball bearings - 10R71915CVUJ74

See technical informationSee documents
References
SNR:10R71924CVUJ74
Rubix:394A4330
EAN:3413521286124
brand logo
brand logo
brand logo
Technical specifications
Inner diameter120 mm
Outer diameter165 mm
Width22 mm
See all Specifications
Documents

Product details : SNR 10R71924CVUJ74 PRECISION BALL BEARINGS

High precision angular contact ball bearing, laminated resin cage centred on outer ring

Technical specifications

Attributes
Logistics dimensions (L x W x H)165x165x22 mm
Logistic Weight1180 g
Inner diameter120 mm
Outer diameter165 mm
Width22 mm
Sealingopen
Seriesmto10r71900
Cagephenolic resin
Basic static load, radial - C0r78800 N
Basic dynamic load, radial - Cr67300 N
Show UNSPSC/ECL@SS
£ 813.21 excl. VAT
/ Each
£ 975.85 incl. VAT
  • Usually arrives within 14 working days
