GUHRING 05511 013.700 RATIO DRILL/COOLING SOLID CARBIDE 13.700MM

GUHRING 05511 013.700 RATIO DRILL/COOLING SOLID CARBIDE 13.700MM

Helicoidal carbide solid drill bit Gühring

References
gühring:05511 013.700
rubix:45004730
ean:4031093575898
Technical specifications
Drilling diameter13.7 mm
Total length124 mm
Length of cut77 mm
See all Specifications

Product details : GUHRING 05511 013.700 RATIO DRILL/COOLING SOLID CARBIDE 13.700MM

Guhring Number 5511 5xD Cylindrical shank Solid Carbide Oil feed drill Futura coated ideally suited for drilling of most ferrous and non-ferrous materials From 3-20mm Diameter

Technical specifications

Attributes
Drilling diameter13.7 mm
Total length124 mm
Length of cut77 mm
Din standardDIN 6537;DIN 6537L
Angle of helix140 °
Tolerancem7
Ratio of diameter to length of drill hole13,7/124 mm
Direction of cuttingRight
Tail diameter14 mm
CoatingNano FIREX
TailStraight
Tip angle140 °
Machining materialSteel;Stainless Steel;Cast Iron;Aluminium;Titanium Alloys;Hardened Steel
Internal coolingYes
Show UNSPSC/ECL@SS
£ 140.50 excl. VAT
/ Each
£ 168.60 incl. VAT

  • Delivery within 10-15 business days
