SKF SPHERICAL ROLLER BEARING 24068CC/W33
Spherical roller bearing SKF
References
skf:24068 CC/W33
rubix:105A0063
manufacturer :36657
ean:7316577119520
Technical specifications
| Inner diameter | 340 mm |
|---|---|
| Outer diameter | 520 mm |
| Width | 180 mm |
Product details : SKF SPHERICAL ROLLER BEARING 24068CC/W33
Spherical roller bearings have two rows of symmetrical rollers, a common sphered outer ring raceway and two inner ring raceways inclined at an angle to the bearing axis. The centre point of the sphere in the outer ring raceway is at the bearing axis.
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 180x520x520 mm |
|---|---|
| Logistic Weight | 138900 g |
| Inner diameter | 340 mm |
| Outer diameter | 520 mm |
| Width | 180 mm |
| Bearing Clearance | CN |
| Series | 240C |
| Reference speed | 750 rpm |
| Limit speed | 1100 rpm |
| Basic static load, radial - C0r | 6200000 N |
| Basic dynamic load, radial - Cr | 2990000 N |
| Sealing | Open |
Show UNSPSC/ECL@SS
£ 5,371.37 excl. VAT
/ Each
£ 6,445.64 incl. VAT
Usually arrives within 14 working days
