TIMKEN QVVSN16V070SM ROLLER BEARING TWO-BOLT PILLOW BLOCK
Housed Unit Bearings
References
timken:QVVSN16V070SM
rubix:255A4685
ean:0883450177634
Technical specifications
| Inner diameter | 70 mm |
|---|---|
| Fixation centre-to-centre distance | 279 mm |
Product details : TIMKEN QVVSN16V070SM ROLLER BEARING TWO-BOLT PILLOW BLOCK
Spherical Roller Bearing Solid-Block Housed Units feature rugged cast-steel housings and double-row spherical roller bearings. Designed to offer protection from contaminants, these housed units accommodate shaft sizes from 1-7/16” to 7” (40 mm to 180 mm) and most metric sizes. This product line was formerly known as “QM Blue Brute Bearings.”
Strengths
The V-Lock locking mechanism is excellent in high-speed applications and designed to maximize shaft-holding power and minimize the time needed for installation and removal as compared to conventional locking mechanisms. With no need for feeler gages during installation, the V-Lock locking mechanism offers superior holding power and is designed to eliminate overtightening. Mechanical withdrawal is a feature of doublenut units.
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 327x97x206 mm |
|---|---|
| Logistic Weight | 16630 g |
| Packaged dimensions (D x W x H) | 327x97x206 mm |
| Package weight | 16630 g |
| Inner diameter | 70 mm |
| Fixation centre-to-centre distance | 279 mm |
| Centre-centre of shaft | 95 mm |
| Height | 183 mm |
| Length | 316 mm |
| Total bearing width | 91 mm |
| Series | QVVSN |
| Diameter of fixation holes | 20 mm |
| Number of holes | 2 |
| Basic static load, radial - C0r | 278000 N |
| Basic dynamic load, radial - Cr | 254000 N |
| Outer diameter | 183 mm |
| Width | 76 mm |
Show UNSPSC/ECL@SS
£ 526.90 excl. VAT
/ Each
£ 632.28 incl. VAT
Usually arrives within 14 working days
