TIMKEN QVVSN26V110SM HOUSED UNIT SOLID BLOCK
Housed Unit Bearings
References
timken:QVVSN26V110SM
rubix:396A6729
ean:0883450081511
Technical specifications
| Inner diameter | 110 mm |
|---|---|
| Fixation centre-to-centre distance | 365 mm |
Product details : TIMKEN QVVSN26V110SM HOUSED UNIT SOLID BLOCK
Spherical Roller Bearing Solid-Block Housed Units feature rugged cast-steel housings and double-row spherical roller bearings. Designed to offer protection from contaminants, these housed units accommodate shaft sizes from 1-7/16” to 7” (40 mm to 180 mm) and most metric sizes. This product line was formerly known as “QM Blue Brute Bearings.”
Strengths
The V-Lock locking mechanism is excellent in high-speed applications and designed to maximize shaft-holding power and minimize the time needed for installation and removal as compared to conventional locking mechanisms. With no need for feeler gages during installation, the V-Lock locking mechanism offers superior holding power and is designed to eliminate overtightening. Mechanical withdrawal is a feature of doublenut units.
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 496x534x451 mm |
|---|---|
| Logistic Weight | 48090 g |
| Packaged dimensions (D x W x H) | 496x534x451 mm |
| Package weight | 48090 g |
| Inner diameter | 110 mm |
| Fixation centre-to-centre distance | 365 mm |
| Centre-centre of shaft | 140 mm |
| Height | 270 mm |
| Length | 410 mm |
| Total bearing width | 146 mm |
| Series | qvvsn |
| Diameter of fixation holes | 24 mm |
| Number of holes | 2 |
| Basic static load, radial - C0r | 945000 N |
| Basic dynamic load, radial - Cr | 757000 N |
| Outer diameter | 270 mm |
| Width | 113 mm |
Show UNSPSC/ECL@SS
£ 1,569.67 excl. VAT
/ Each
£ 1,883.60 incl. VAT
Usually arrives within 14 working days
