INA TFE60-XL FLANGED BEARING HOUSING UNIT4 HOLE WITH CENTERING PILOT W
Housing Unit
References
ina:TFE60-XL
rubix:238A0784
manufacturer :0004812380000
ean:4012802785036
Technical specifications
| Inner diameter | 60 mm |
|---|---|
| Width | 77.9 mm |
| Fixation centre-to-centre distance | 165 mm |
Product details : INA TFE60-XL FLANGED BEARING HOUSING UNIT4 HOLE WITH CENTERING PILOT W
four-bolt flanged housing units, cast iron, centring spigot, eccentric locking collar, T seals
Technical specifications
Attributes
| Inner diameter | 60 mm |
|---|---|
| Width | 77.9 mm |
| Fixation centre-to-centre distance | 165 mm |
| Material | Cast Iron |
| Series | TFE |
| Total bearing width | 77.9 mm |
| Diameter of fixation holes | 14 mm |
| Number of holes | 4 |
| Basic static load, radial - C0r | 36000 N |
| Basic dynamic load, radial - Cr | 56000 N |
| Outer diameter | 195 mm |
Show UNSPSC/ECL@SS
£ 141.88 excl. VAT
/ Each
£ 170.26 incl. VAT
Usually arrives within 14 working days
