C34611.0 LONG SERIES END MILL
Key-way cutter C346
References
dormer:C34611.0
rubix:302A1373
ean:7320760126240
Technical specifications
| Diameter | 11 mm |
|---|---|
| Type of tail | WELDON |
| Tail diameter | 12 mm |
Product details : C34611.0 LONG SERIES END MILL
HSS-E-PM Extra-length key-way cutter with weld-on shaft DIN 844L N 30° uncoated 3-cutter for non-alloyed steel <700 N/mm². Titanium. Nickel and copper alloys.
Applications
• Construction steel carburised steel (<200 HB <700 N/mm²)
• Titanium non-alloyed (<200 HB <700 N/mm²)
• nickel non-alloyed (<200 HB <700 N/mm²)
• Copper (<100 HB <350 N/mm²)
• Béta-Brass Bronze (<200 HB <700 N/mm²)
• Alfa-Brass (<200 HB <700 N/mm²)
• Titanium non-alloyed (<200 HB <700 N/mm²)
• nickel non-alloyed (<200 HB <700 N/mm²)
• Copper (<100 HB <350 N/mm²)
• Béta-Brass Bronze (<200 HB <700 N/mm²)
• Alfa-Brass (<200 HB <700 N/mm²)
Technical specifications
Attributes
| Diameter | 11 mm |
|---|---|
| Type of tail | WELDON |
| Tail diameter | 12 mm |
| Number of teeth | 3 |
| Total length | 102 mm |
| Body material | HSS-E |
| Capacity length | 45 mm |
| Cutting angle | 30 ° |
Show UNSPSC/ECL@SS
£ 50.50 excl. VAT
/ Each
£ 60.60 incl. VAT
Usually arrives within 14 working days
