BLICKLE BH-ALBS82K CASTOR
Levelling castor, with integrated truck lock and bolt hole Nylon wheel
References
blickle:BH-ALBS 82K
rubix:218A5261
manufacturer :754035
ean:4047526076351
Technical specifications
| Load capacity | 230 kg |
|---|---|
| Wheel diameter | 80 mm |
| Wheel width | 40 mm |
Product details : BLICKLE BH-ALBS82K CASTOR
Bracket: HRIG series
- die-cast aluminium, powder-coated, colour ivory
- sealed ball bearing in the swivel head
- hexagonal steel top plate
- female thread in bolt hole
- truck lock made of hard rubber
- height adjustment using wrench or integrated adjustment wheel
- steel parts zinc-plated, blue-passivated, Cr6-free
Wheel: POA series
- high-quality nylon 6, impact resistant, hardness 70 Shore D, colour black
- Load capacity determined under the following conditions:
– speed: max. 1 km/h
– temperature: +15 °C to +30 °C
– hardness, horizontal tread without obstacles
– route: A cooling off period of 15 minutes is required after a maximum of 50 m
Technical specifications
Attributes
| Logistic Weight | 930 g |
|---|---|
| Load capacity | 230 kg |
| Wheel diameter | 80 mm |
| Wheel width | 40 mm |
| Wheel housing/rim material | Aluminium |
| Running sole/tire material | Polyurethane |
| Type of bearing | Ball bearing |
| Running sole / tire colour | Blue |
| Shore A Hardness | 75 Shore |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| 120 mm | |
| 40 mm |
Show UNSPSC/ECL@SS
£ 56.04 excl. VAT
/ Each
£ 67.25 incl. VAT
Usually arrives within 14 working days
