BLICKLE FIXED CASTOR BKPA-POA-80G
Pressed steel swivel castor, with top plate fitting, with brake system 'stop-top' Nylon wheel, with steel thread guard
References
blickle:BKPA-POA 80G
rubix:155A1544
manufacturer :576975
ean:4047526576974
Technical specifications
| Load capacity | 120 kg |
|---|---|
| Wheel diameter | 80 mm |
| Wheel width | 32 mm |
Product details : BLICKLE FIXED CASTOR BKPA-POA-80G
Bracket: LE series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
- double ball bearing in the swivel head
- swivel head seal
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: PO series
- high-quality nylon 6, impact resistant, hardness 70 Shore D, colour natural white
- high chemical resistance to many aggressive substances
- operating temperature: -25 °C to +80 °C, reduced load capacity over +35 °C
Technical specifications
Attributes
| Logistic Weight | 412 g |
|---|---|
| Load capacity | 120 kg |
| Wheel diameter | 80 mm |
| Wheel width | 32 mm |
| Wheel housing/rim material | Polyamide |
| Running sole/tire material | Polyamide |
| Shore D Hardness | 70 Shore |
| Type of bearing | Plain bore |
| Running sole / tire colour | Black |
| Min. temperature | -25 °C |
| Max. temperature | 80 °C |
| 111 mm | |
| 33 mm |
Show UNSPSC/ECL@SS
£ 11.67 excl. VAT
/ Each
£ 14.00 incl. VAT
Usually arrives within 14 working days
