DORMER E252M16 TAP M16 X 2.00 MM 5975258
Machine thread-cutters E252
References
dormer:E252M16
rubix:2557081
ean:7320760087299
Technical specifications
| Threading | M16 |
|---|---|
| Threading diameter | 16 mm |
| Input | 12 |
Product details : DORMER E252M16 TAP M16 X 2.00 MM 5975258
HSS-E-PM Machine thread-cutter for metric threaded SHARK white ring nitrided DIN 376 shape C straight grooves 2xD blind and continuous holes for cast iron and synthetic materials such as duraplastics.
TARAUD M 16 E252 MAC XP GD DIN 371
Applications
• Cast Iron lamellar (<150 HB>500 N/mm²)
• Cast Iron lamellar (>150<300 HB>500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Plastic - Duraplastics
• Cast Iron lamellar (>150<300 HB>500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Plastic - Duraplastics
Technical specifications
Attributes
| Threading | M16 |
|---|---|
| Threading diameter | 16 mm |
| Input | 12 |
| Total length | 110 mm |
| Body material | HSS-E |
| Type | Metric blind bores and through-bores |
| With cooling spray | No |
| Drilling diameter | 14 mm |
| Square drive adapter | 12 mm |
| Coating | Steam tempered |
Show UNSPSC/ECL@SS
£ 51.87 excl. VAT
/ Each
£ 62.24 incl. VAT
Usually arrives within 14 working days
