BLICKLE FPTH-80X20/20-14K FPTH 80X20/20-14K
Stainless steel swivel castor, with bolt hole fitting Nylon wheel
References
blickle:FPTH 80x20/20-14K
rubix:155A9453
manufacturer :842325
ean:4047526122782
Technical specifications
| Load capacity | 150 kg |
|---|---|
| Wheel diameter | 80 mm |
| Wheel width | 20 mm |
Product details : BLICKLE FPTH-80X20/20-14K FPTH 80X20/20-14K
Bracket: LEXR series
- high-quality chromium-nickel steel (1.4301/AISI 304), stainless steel, vibration-ground finishing
- double ball bearing in the swivel head
- strong central kingpin
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
- all parts including axle material are corrosion-resistant
Wheel: PO series
- high-quality nylon 6, impact resistant, hardness 70 Shore D, colour natural white
- high chemical resistance to many aggressive substances
- operating temperature: -25 °C to +80 °C, reduced load capacity over +35 °C
Technical specifications
Attributes
| Logistic Weight | 174 g |
|---|---|
| Load capacity | 150 kg |
| Wheel diameter | 80 mm |
| Wheel width | 20 mm |
| Wheel housing/rim material | Polyamide |
| Running sole/tire material | Polyurethane |
| Running sole / tire colour | Grey |
| Shore A Hardness | 92 Shore |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| 20 mm |
Show UNSPSC/ECL@SS
£ 15.97 excl. VAT
/ Each
£ 19.16 incl. VAT
Usually arrives within 14 working days
