Angular contact ball bearing SNR 7316BGM, Outer diameter: 170 mm | Inner diameter: 80 mm | Width: 39 mm

SNR angular contact ball bearing

See technical informationSee documents

References

SNR:7316BGM
Rubix:205A1220
EAN:3413520207571
brand logo
brand logo
brand logo

Technical specifications

Inner diameter80 mm
Outer diameter170 mm
Width39 mm
See all Specifications

Documents

Product details : SNR 7316BGM ANGULAR CONTACT BALL BEARING

Angular contact ball bearing with brass cage, ball guided
Single row angular contact ball bearing, solid brass cage, rolling body guided, universal bearing pairing without preload

Technical specifications

Attributes
Logistics dimensions (L x W x H)187x180x54 mm
Logistic Weight4152 g
Inner diameter80 mm
Outer diameter170 mm
Width39 mm
Bearing Clearancecn
Sealingopen
Series7300
Materialsteel
Cagebrass
Reference speed4400 rpm
Limit speed5100 rpm
Angle40 °
Basic static load, radial - C0r115000 N
Basic dynamic load, radial - Cr138000 N
£ 251.63 excl. VAT
/ Each
£ 301.96 incl. VAT
  • Usually arrives within 14 working days
