SKF SPHERICAL ROLLER BEARING 23956 CCK/W33
Spherical Roller Bearing
References
skf:23956 CCK/W33
rubix:105A1786
manufacturer :36469
ean:7316571097060
Technical specifications
| Inner diameter | 280 mm |
|---|---|
| Outer diameter | 380 mm |
| Width | 75 mm |
Product details : SKF SPHERICAL ROLLER BEARING 23956 CCK/W33
Spherical roller bearings have two rows of symmetrical rollers, a common sphered outer ring raceway and two inner ring raceways inclined at an angle to the bearing axis. The centre point of the sphere in the outer ring raceway is at the bearing axis.
Strengths
- Accommodate misalignment
- High load carrying capacity
- Relubrication features
- Low friction and long service life
- Increased wear resistance
- High load carrying capacity
- Relubrication features
- Low friction and long service life
- Increased wear resistance
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 75x380x380 mm |
|---|---|
| Logistic Weight | 23800 g |
| Inner diameter | 280 mm |
| Outer diameter | 380 mm |
| Width | 75 mm |
| Bearing Clearance | CN |
| Series | 239C |
| Reference speed | 1600 rpm |
| Limit speed | 1700 rpm |
| Basic static load, radial - C0r | 1760000 N |
| Basic dynamic load, radial - Cr | 845000 N |
| Sealing | Open |
Show UNSPSC/ECL@SS
£ 1,989.51 excl. VAT
/ Each
£ 2,387.41 incl. VAT
In stock: Next day delivery
