BLICKLE-FTH50X18/15-11K GUIDE ROLLER
Stainless steel swivel castor, with bolt hole fitting Wheel, with standard solid rubber tyre, with synthetic rim, non-marking, grey
References
blickle:FTH 50x18/15-11K
rubix:203A9167
manufacturer :463810
ean:4047526463816
Technical specifications
| Load capacity | 80 kg |
|---|---|
| Wheel diameter | 50 mm |
| Wheel width | 18 mm |
Product details : BLICKLE-FTH50X18/15-11K GUIDE ROLLER
Bracket: LEXR series
- high-quality chromium-nickel steel (1.4301/AISI 304), stainless steel, vibration-ground finishing
- double ball bearing in the swivel head
- strong central kingpin
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
- all parts including axle material are corrosion-resistant
Wheel: VPP series
- tyre: standard solid rubber, hardness 80 Shore A, colour grey, non-marking
- rim: high-quality polypropylene, impact resistant, colour black
- high chemical resistance to many aggressive substances, except oils
- operating temperature: -20 °C to +60 °C, reduced load capacity over +30 °C
Technical specifications
Attributes
| Logistic Weight | 67 g |
|---|---|
| Load capacity | 80 kg |
| Wheel diameter | 50 mm |
| Wheel width | 18 mm |
| Running sole/tire material | Polyurethane |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| Running sole / tire colour | Brown |
| Shore A Hardness | 92 Shore |
| 18 mm |
Show UNSPSC/ECL@SS
£ 23.21 excl. VAT
/ Each
£ 27.85 incl. VAT
Usually arrives within 14 working days
