TSUBAKI 72216080000-M3.05 RS80-LMD NEPTUNE 1 DWG CR010.102905-E 10FT


ANSI Lambda Neptune Chain

References
tsubaki:RSD80 LAMBDA N.E.P. RP
rubix:267A0676
manufacturer :2216080000
ean:8718472786408
brand logo
brand logo
Technical specifications
Chain pitch25.4 mm
Chain length3050 mm
Profilesimplex (1)
See all Specifications

Product details : TSUBAKI 72216080000-M3.05 RS80-LMD NEPTUNE 1 DWG CR010.102905-E 10FT


ANSI Lambda Neptune™ Chain is a Tsubaki ANSI Lambda chain that has undergone a special surface treatment. The link plates have a special two stage layer applied in order to provide the maximum protection from the operating or environmental conditions. This chain is suitable for use in applications that are subject to akaline cleaning and environments exposed to seawater, acid-rain and other adverse weather conditions. This chain does not contain any chemically hazardous substances such as Hexavalent Chromium, Lead, Cadmium and Mercury as regulated by RoHS.

Technical specifications


Attributes
Chain pitch25.4 mm
Chain length3050 mm
Profilesimplex (1)
Chainasa 80-1
ISO code16a-1
Weight8455 kg
Inner width min.15.48 mm
Roller diameter15.88 mm
Pin length39.9 mm
Tensile strength min.71.6 kN
Plate height24.1 mm
Plate thickness4 mm
Inner link width15.48 mm
Chain pin diameter7.94 mm
Show UNSPSC/ECL@SS
£ 758.11 excl. VAT
/ Each
£ 909.73 incl. VAT
  • Usually arrives within 14 working days
