SKF SY 1.3/4 TF/VA228 HIGH TEMPERATURE BEARINGS
Ball bearing unit
See technical informationSee documentsReferences
SKF:SY 1.3/4 TF/VA228
Rubix:237A4329
Manufacturer :114758
EAN:07316571381138
Technical specifications
| Inner diameter | 44.45 mm |
|---|---|
| Fixation centre-to-centre distance | 152 mm |
| Material | cast iron (housing);steel (bearing) |
Documents
Product details : SKF SY 1.3/4 TF/VA228 HIGH TEMPERATURE BEARINGS
Y plummer block unit for high temperatures with cast housing and set-screw mounting.
Strengths
- Accommodate heavy loads in different directions
- High degree of stiffness
- Narrow design
- High degree of stiffness
- Narrow design
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 54,2x187x44,45 mm |
|---|---|
| Logistic Weight | 2244 g |
| Inner diameter | 44.45 mm |
| Fixation centre-to-centre distance | 152 mm |
| Material | cast iron (housing);steel (bearing) |
| Total bearing width | 49.2 mm |
| Outer diameter | 56.8 mm |
| Diameter of fixation holes | 12 mm |
| Height | 107 mm |
| Length | 187 mm |
| Series | sy |
| Weight | 2.2 kg |
| Number of holes | 2 |
| Width | 48 mm |
Show UNSPSC/ECL@SS
£ 218.42 excl. VAT
/ Each
£ 262.10 incl. VAT
- Usually arrives within 14 working days
