TIMKEN UCF213 FOUR BOLT FLANGED BEARING UNIT
Flanged Housed Unit
References
timken:UCF213
rubix:211A4584
ean:0087796073883
Technical specifications
| Inner diameter | 65 mm |
|---|---|
| Width | 187 mm |
| Fixation centre-to-centre distance | 149 mm |
Product details : TIMKEN UCF213 FOUR BOLT FLANGED BEARING UNIT
Timken innovations continue to keep the world in motion, including the invention of the wide inner ring bearing and the ball bearing housed unit. We continue that innovation by applying our extensive engineering knowledge of bearings, metallurgy, seals and end-user applications to deliver optimized performance from our housed unit product line
Strengths
- UCP pillow blocks are suggested for industrial applications where normal loads are encountered
- Compact, one-piece housing with two-bolt mounting can be installed in any position and makes bearing replacement easy
- These units use wide inner ring ball bearings with self-aligning spherical outside diameters that compensate for shaft misalignment
- Bearing prelubricated and ready for immediate installation
- Grease fitting supplied for relubrication
- The bonded seal design is well-suited for applications involving wet or dirty environments
- Bolt-hole spacing and base to center height dimensions are interchangeable with competitive units
Technical specifications
Attributes
| Inner diameter | 65 mm |
|---|---|
| Width | 187 mm |
| Fixation centre-to-centre distance | 149 mm |
| Material | Cast Iron |
| Height | 69.7 mm |
| Length | 187 mm |
| Series | U |
| Total bearing width | 50 mm |
| Diameter of fixation holes | 19 mm |
| Number of holes | 4 |
| Basic static load, radial - C0r | 40100 N |
| Basic dynamic load, radial - Cr | 57200 N |
| Weight | 4.2 kg |
Show UNSPSC/ECL@SS
£ 176.31 excl. VAT
/ Each
£ 211.57 incl. VAT
Usually arrives within 14 working days
