DORMER E650 HSS COMBINATION DRILL/TAP TAP M5
Machine taps E650
References
dormer:E650M5
rubix:1006388
ean:7320760127568
Technical specifications
| Threading diameter | 5 mm |
|---|---|
| Thread | 0,8 mm |
| Body material | HSS |
Product details : DORMER E650 HSS COMBINATION DRILL/TAP TAP M5
HSS combi-drill/tap voor metric threads steam tempered shape C 30° spiralled 1.5xD continuous holes for general use in steel <850 N/mm². Cast iron Copper and brass. Aluminium alloys Si <0.5% en thermoplasts.
Applications
• Machining steel soft steel (<120 HB <400 N/mm²)
• Construction steel carburised steel (<200 HB <700 N/mm²)
• Carbon steel (<250 HB <850 N/mm²)
• Alloyed steel (<250 HB <850 N/mm²)
• Cast iron lamellar (> 150<300 HB >500<1000 N/mm²)
• Béta-Brass Bronze (<200 HB <700 N/mm²)
• Alfa-Brass (<200 HB <700 N/mm²)
• Aluminium Magnesium non-alloyed (<100 HB <350 N/mm²)
• Aluminium alloyed Silicon 0.5% (<150 HB <500 N/mm²)
• Plastic-Thermoplastics
• Construction steel carburised steel (<200 HB <700 N/mm²)
• Carbon steel (<250 HB <850 N/mm²)
• Alloyed steel (<250 HB <850 N/mm²)
• Cast iron lamellar (> 150<300 HB >500<1000 N/mm²)
• Béta-Brass Bronze (<200 HB <700 N/mm²)
• Alfa-Brass (<200 HB <700 N/mm²)
• Aluminium Magnesium non-alloyed (<100 HB <350 N/mm²)
• Aluminium alloyed Silicon 0.5% (<150 HB <500 N/mm²)
• Plastic-Thermoplastics
Technical specifications
Attributes
| Threading diameter | 5 mm |
|---|---|
| Thread | 0,8 mm |
| Body material | HSS |
| Square drive adapter | 5 mm |
| Material | HSS |
| Input | 5 |
| Angle of helix | 30 ° |
| Total length | 69 mm |
Show UNSPSC/ECL@SS
£ 47.28 excl. VAT
/ Each
£ 56.74 incl. VAT
In stock: Next day delivery
