DORMER E5501/2 TAP 1/2 INCH X 14 5976459
Machine thread-cutters E550
References
dormer:E5501/2
rubix:021322
ean:7320760099476
Technical specifications
| Input | 16 |
|---|---|
| Total length | 87 mm |
| Body material | HSS |
Product details : DORMER E5501/2 TAP 1/2 INCH X 14 5976459
HSS Machine thread-cutters for Rc thread uncoated ISO 2284 shape C straight grooves 1.5xD blind and continual holes for cast iron and copper.
TARAUD MACHINE 1/2 RC E550 GAZ CON GD BSPT
Applications
• Cast Iron lamellar (<150 HB >500 N/mm ²)
• Cast iron lamellar (>150<300 HB >500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Ductile cast iron/malleable cast iron (>200<300 HB >700<1000 N/mm²)
• Copper (<100 HB <350 N/mm²)
• Cast iron lamellar (>150<300 HB >500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Ductile cast iron/malleable cast iron (>200<300 HB >700<1000 N/mm²)
• Copper (<100 HB <350 N/mm²)
Technical specifications
Attributes
| Input | 16 |
|---|---|
| Total length | 87 mm |
| Body material | HSS |
| Type | British blind bores and through-bores |
| With cooling spray | No |
| Drilling diameter | 18.25 mm |
| Square drive adapter | 16 mm |
| Coating | Blank |
Show UNSPSC/ECL@SS
£ 81.90 excl. VAT
/ Each
£ 98.28 incl. VAT
Usually arrives within 14 working days
