TSUBAKI 5003000170 TFS-17 CAM CLUTCH
TFS-45 CAM CLUTCH
References
tsubaki:TFS17
rubix:267A0295
manufacturer :5003000170
ean:8718472212280
Technical specifications
| Inner diameter | 22 mm |
|---|---|
| Outer diameter | 47 mm |
| Width | 19 mm |
Product details : TSUBAKI 5003000170 TFS-17 CAM CLUTCH
Tsubaki TFS Series clutches are designed for press fit installation. Outside dimensions are the same as 63** ball bearings. TFS Clutches have two vertical key ways on the outer races. The usage of bearing support is compulsory.
Technical specifications
Attributes
| Logistic Weight | 188 g |
|---|---|
| Inner diameter | 22 mm |
| Outer diameter | 47 mm |
| Width | 19 mm |
| Series | TFS |
| Weight | 0.188 kg |
| Reference speed | 1600 rpm |
| Auth. torque | 50 N.m |
| Standard | DIN 6885. 1;DIN 6885. 3 |
Show UNSPSC/ECL@SS
£ 116.57 excl. VAT
/ Each
£ 139.88 incl. VAT
Usually arrives within 14 working days
