DORMER R1203.4 R120 3.40 MM CARBIDE STRAIGHT SHANSTUB DRILL 5979433
Helicoidal carbide solid drill bit Dormer
References
dormer:R1203.4
rubix:293A7437
ean:7320760114254
Technical specifications
| Drilling diameter | 3.4 mm |
|---|---|
| Total length | 52 mm |
| Length of cut | 20 mm |
Product details : DORMER R1203.4 R120 3.40 MM CARBIDE STRAIGHT SHANSTUB DRILL 5979433
For drilling most materials up to x2.5 diameter. Manufactured from premium grade Solid Carbide which permits increased machining speeds and longer tool life. Manufactured To DIN 1897 Standards.
Other metric size drills available on request.
Other metric size drills available on request.
Technical specifications
Attributes
| Drilling diameter | 3.4 mm |
|---|---|
| Total length | 52 mm |
| Length of cut | 20 mm |
| Din standard | DIN 6539 |
| Ratio of diameter to length of drill hole | 2,5xD |
| Tip angle | 120 ° |
| Internal cooling | No |
Show UNSPSC/ECL@SS
£ 15.72 excl. VAT
/ Each
£ 18.86 incl. VAT
Usually arrives within 14 working days
