BLICKLE 7682 L-G 150G CASTOR
Light duty swivel castor, with bolt hole fitting, with synthetic expander, with brake system 'stop-fix' Nylon wheel
References
blickle:L-G 150G
rubix:225A6380
manufacturer :7682
ean:4047526007683
Technical specifications
| Load capacity | 400 kg |
|---|---|
| Wheel diameter | 150 mm |
| Wheel width | 50 mm |
Product details : BLICKLE 7682 L-G 150G CASTOR
Bracket: LKRA series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
- double ball bearing in the swivel head
- strong central kingpin
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: POA series
- high-quality nylon 6, impact resistant, hardness 70 Shore D, colour black
- high chemical resistance to many aggressive substances
- operating temperature: -25 °C to +80 °C, reduced load capacity over +35 °C
Technical specifications
Attributes
| Logistic Weight | 4360 g |
|---|---|
| Load capacity | 400 kg |
| Wheel diameter | 150 mm |
| Wheel width | 50 mm |
| Wheel housing/rim material | Cast Iron |
| Running sole/tire material | Cast Iron |
| Min. temperature | -25 °C |
| Max. temperature | 70 °C |
| Total height | 190 mm |
| Type of bearing | Plain bore |
| Running sole / tire colour | Silver |
| Plate width | 110 mm |
| Plate length | 140 mm |
| 190 mm | |
| 50 mm |
Show UNSPSC/ECL@SS
£ 92.23 excl. VAT
/ Each
£ 110.68 incl. VAT
Usually arrives within 14 working days
