WALTERPROT 23207-UNF6 TAP 5078425

Machine Tap

See technical informationSee documents

References

Walter Prototyp:23207-UNF6
Rubix:251A3895
Manufacturer :5078425
EAN:4042446029005
brand logo

Technical specifications

Threadingunf #6-40
Threading diameter3.505 mm
Typeamerican blind bores
See all Specifications

Documents

Product details : WALTERPROT 23207-UNF6 TAP 5078425

ALTIUS

Strengths

•Recommended with oil
For long-chipping materials

Applications

Through Hole Thread

Technical specifications

Attributes
Threadingunf #6-40
Threading diameter3.505 mm
Typeamerican blind bores
With cooling sprayno
Direction of threadingright
Drilling diameter3.505 mm
Tail diameter4 mm
Square drive adapter3 mm
Thread depth12 mm
Angle of helix0 °
Coatinguncoated
Total length56 mm
Body materialhss-e / pm
Threadingunf #6 - 40
No. of threads per inch40
Tolerance3b
£ 72.64 excl. VAT
/ Each
£ 87.17 incl. VAT
  • Usually arrives within 14 working days
