SKF UCPA 208/H BALL BEARING UNIT
Plummer Block Ball Bearing Unit
References
skf:UCPA 208/H
rubix:388A6251
ean:7316579751896
Technical specifications
| Inner diameter | 40 mm |
|---|---|
| Fixation centre-to-centre distance | 84 mm |
| Shaft Height | 49.2 mm |
Product details : SKF UCPA 208/H BALL BEARING UNIT
Short base pillow (plummer) block ball bearing units consist of an insert bearing mounted in a cast iron housing. This variant has threaded holes for attachment bolts and is suitable for applications where the direction of rotation is constant or alternating. It has an inner ring extended on both sides and is locked onto the shaft by tightening two set screws on the inner ring, making it easy to mount. The units are compliant with Japanese Industrial Standards (JIS).
Strengths
•Optimized for applications where space is limited
Ready to mount
Lubricated and sealed bearing
Quick locking onto the shaft
Extended inner ring for minimized shaft misalignment
Ready to mount
Lubricated and sealed bearing
Quick locking onto the shaft
Extended inner ring for minimized shaft misalignment
Technical specifications
Attributes
| Inner diameter | 40 mm |
|---|---|
| Fixation centre-to-centre distance | 84 mm |
| Shaft Height | 49.2 mm |
| Material | Cast Iron |
| Height | 98 mm |
| Length | 115.9 mm |
| Total bearing width | 44.5 mm |
| Series | UCPA |
| Weight | 1.67 kg |
| Number of holes | 2 |
| Outer diameter | 51.8 mm |
| Width | 49.2 mm |
Show UNSPSC/ECL@SS
£ 32.60 excl. VAT
/ Each
£ 39.12 incl. VAT
Usually arrives within 14 working days
