BLICKLE SWIVEL CASTOR 100MM L-ALEV-100K-FIEL
Pressed steel swivel castor, heavy duty design, with top plate fitting Nylon wheel, with steel thread guard
References
blickle:L-ALEV 100K-FI-EL
rubix:155A0596
manufacturer :610113
ean:4047526610111
Technical specifications
| Load capacity | 200 kg |
|---|---|
| Wheel diameter | 100 mm |
| Wheel width | 40 mm |
Product details : BLICKLE SWIVEL CASTOR 100MM L-ALEV-100K-FIEL
Bracket: LH series
- strong pressed steel, zinc-plated, blue-passivated, Cr6-free
- heavy fork and top plate
- double ball bearing in the swivel head
- bolted and secured central kingpin, extremely strong
- particularly resistant to shocks and impact due to four specially-shaped, hardened bearing seats
Wheel: PO series
- high-quality nylon 6, impact resistant, hardness 70 Shore D, colour natural white
- high chemical resistance to many aggressive substances
- operating temperature: -20 °C to +80 °C, reduced load capacity over +35 °C
Technical specifications
Attributes
| Logistic Weight | 1070 g |
|---|---|
| Load capacity | 200 kg |
| Wheel diameter | 100 mm |
| Wheel width | 40 mm |
| Wheel housing/rim material | Aluminium |
| Running sole/tire material | Rubber |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| Total height | 125 mm |
| Type of bearing | Ball bearing |
| Running sole / tire colour | Black |
| Shore A Hardness | 71 Shore |
| Plate width | 85 mm |
| Plate length | 100 mm |
| 125 mm | |
| 40 mm |
Show UNSPSC/ECL@SS
£ 49.01 excl. VAT
/ Each
£ 58.81 incl. VAT
Usually arrives within 14 working days
