BLICKLE HTH 80X56/20-56K ROLLERS
Pressed steel swivel castor, heavy duty design, with top plate fitting, with brake system 'stop-top' Heavy duty wheel, with Blickle Extrathane® polyurethane tread, with aluminium wheel centre, antistatic
References
blickle:HTH 80X56/20-56K
rubix:227A6949
manufacturer :269654
ean:4047526269654
Technical specifications
| Load capacity | 500 kg |
|---|---|
| Wheel diameter | 80 mm |
| Wheel width | 56 mm |
Product details : BLICKLE HTH 80X56/20-56K ROLLERS
Bracket: LH series
- strong pressed steel, zinc-plated, blue-passivated, Cr6-free
- heavy fork and top plate
- double ball bearing in the swivel head
- bolted and secured central kingpin, extremely strong
- particularly resistant to shocks and impact due to four specially-shaped, hardened bearing seats
Wheel: ALTH series
- tread: high-quality polyurethane elastomer Blickle Extrathane®, hardness 92 Shore A, colour grey, non-marking, non-staining
- wheel centre: die-cast aluminium, colour silver grey
- high chemical resistance to many aggressive substances
- operating temperature: -20 °C to +70 °C, temporarily up to +90 °C, reduced load capacity over +40 °C
- electrical conductivity (ohmic resistance) ≤ 107 Ω
Technical specifications
Attributes
| Logistic Weight | 864 g |
|---|---|
| Load capacity | 500 kg |
| Wheel diameter | 80 mm |
| Wheel width | 56 mm |
| Wheel housing/rim material | metal |
| Running sole/tire material | polyurethane |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| Running sole / tire colour | brown |
| Shore A Hardness | 92 Shore |
| 56 mm |
Show UNSPSC/ECL@SS
£ 33.61 excl. VAT
/ Each
£ 40.33 incl. VAT
Usually arrives within 14 working days
