BLICKLE 486985 BSD-GTH 304K TWIN WHEEL
Pressed steel swivel castor, with bolt hole, with brake system 'stop-fix' Wheel, with standard solid rubber tyre, with synthetic rim
References
blickle:BSD-GTH 304K
rubix:237A3488
manufacturer :486985
ean:4047526486983
Technical specifications
| Load capacity | 5400 kg |
|---|---|
| Wheel diameter | 300 mm |
| Wheel width | 100 mm |
Product details : BLICKLE 486985 BSD-GTH 304K TWIN WHEEL
Bracket: LER series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
- double ball bearing in the swivel head
- strong central kingpin
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: VPP series
- tyre: standard solid rubber, hardness 80 Shore A, colour black
- rim: high-quality polypropylene, impact resistant, colour black
- high chemical resistance to many aggressive substances, except oils
- operating temperature: -20 °C to +60 °C, reduced load capacity over +30 °C
Technical specifications
Attributes
| Logistic Weight | 55760 g |
|---|---|
| Load capacity | 5400 kg |
| Wheel diameter | 300 mm |
| Wheel width | 100 mm |
| Wheel housing/rim material | Cast Iron |
| Running sole/tire material | Polyurethane |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| Total height | 390 mm |
| Type of bearing | Ball bearing |
| Running sole / tire colour | Brown |
| Shore A Hardness | 92 Shore |
| Plate width | 200 mm |
| Plate length | 300 mm |
| 390 mm | |
| 2x100 mm |
Show UNSPSC/ECL@SS
£ 1,554.30 excl. VAT
/ Each
£ 1,865.16 incl. VAT
Usually arrives within 14 working days
