BLICKLE GUIDE ROLLER FSTH 40X15/10-8K
Stainless steel swivel castor, with bolt hole fitting, with brake system 'stop-fix' Nylon wheel, with synthetic thread guard
References
blickle:FSTH 40x15/10-8K
rubix:156A0217
manufacturer :463927
ean:4047526463922
Technical specifications
| Load capacity | 70 kg |
|---|---|
| Wheel diameter | 40 mm |
| Wheel width | 15 mm |
Product details : BLICKLE GUIDE ROLLER FSTH 40X15/10-8K
Bracket: LEXR series
- high-quality chromium-nickel steel (1.4301/AISI 304), stainless steel, vibration-ground finishing
- double ball bearing in the swivel head
- strong central kingpin
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
- all parts including axle material are corrosion-resistant
Wheel: PO series
- high-quality nylon 6, impact resistant, hardness 70 Shore D, colour natural white
-
small thread guard
with additional
ball bearing seal
- high chemical resistance to many aggressive substances
- operating temperature: -20 °C to +80 °C, reduced load capacity over +35 °C
Technical specifications
Attributes
| Logistic Weight | 61 g |
|---|---|
| Load capacity | 70 kg |
| Wheel diameter | 40 mm |
| Wheel width | 15 mm |
| Wheel housing/rim material | Steel |
| Running sole/tire material | Polyurethane |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| Running sole / tire colour | Brown |
| Shore A Hardness | 92 Shore |
| 15 mm |
Show UNSPSC/ECL@SS
£ 36.60 excl. VAT
/ Each
£ 43.92 incl. VAT
Usually arrives within 14 working days
