BLICKLE FTH30X14/5-12K GUIDE ROLLER
Stainless steel swivel castor, with top plate fitting, with brake system 'stop-fix' Wheel, with thermoplastic rubber tread, with polypropylene wheel centre, electrically conductive, non-marking
References
blickle:FTH 30x14/5-12K
rubix:248A0821
manufacturer :744178
ean:4047526110239
Technical specifications
| Load capacity | 50 kg |
|---|---|
| Wheel diameter | 30 mm |
| Wheel width | 14 mm |
Product details : BLICKLE FTH30X14/5-12K GUIDE ROLLER
Bracket: LEX series
- high-quality chromium-nickel steel (1.4301/AISI 304), stainless steel, vibration-ground finishing
- all parts including axle material are corrosion-resistant
- double ball bearing in the swivel head
- swivel head seal
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: TPA series
- tread: high-quality thermoplastic rubber-elastomer (TPE), hardness 85 Shore A, colour grey, non-marking, oil containing
- wheel centre: high-quality polypropylene, impact resistant, colour black
- very high chemical resistance to many aggressive substances
- operating temperature: -20 °C to +60 °C, reduced load capacity over +30 °C
- tread contains oil, may stain sensitive surfaces. alternatives: series VPA, PATH
- electrical conductivity (ohmic resistance) ≤ 104 Ω
Technical specifications
Attributes
| Logistic Weight | 24 g |
|---|---|
| Load capacity | 50 kg |
| Wheel diameter | 30 mm |
| Wheel width | 14 mm |
| Running sole/tire material | polyurethane |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| Running sole / tire colour | brown |
| Shore A Hardness | 92 Shore |
| 14 mm |
Show UNSPSC/ECL@SS
£ 34.02 excl. VAT
/ Each
£ 40.82 incl. VAT
Usually arrives within 14 working days
